Description
Double Clip Pipe Repair Clamp
Pipe repair clamps are suitable for surface/underground engineering, shipbuilding/offshore oil platform, water, gas/natural
gas supply, power, industrial production, sewage treatment and maintenance, etc.
Repair clamp is made of stainless steel and rubber to achieve the function of sealing and pressure bearing.The structure is
very compact. During the construction, no treatment is required for the pipe end. As long as the connector is sleeved on the
two pipe ends to be connected, and the side bolts are tightened, the sealing sleeve can tightly stick on the pipe to achieve
the locking state of tight connection.
Material :
Casing :AISI 304 OR 316
Sealing:EPDM (working temperature -30 ℃-150℃ )(suitable for water air solid and chemicals )
NBR (working temperature - 25 ℃-110℃ )(suitable for gas oil and fuel )
FKM MVQ is available
MODEL
DIAMETER
(MM)
PIPE OD
(MM)
COMMON LENGTH
(MM)
LONGER TYPE
(MM)
PRESSURE
(MPA)
PRELOAD
(NM)
WO-DN25
34
33-35
60
100
2.5
50-80
WO-DN32
42
42-44
60
100
2.5
50-100
WO-DN40
48.6
47-49
60
100
2.5
50-100
WO-DN50
60
59-62
80
140
2.0
100-150
WO-DN65
76
75-78
80
140
2.0
100-150
WO-DN80
89
88-92
100
205
2.0
150-200
WO-DN100
114
108-116
100
205
1.6
150-200
WO-DN125
140
137-142
110
205
1.6
250-300
WO-DN150
159
157-162
110
205
1.6
250-300
WO-DN160
168
165-170
140
205
1.6
250-300
WO-DN200
219
217-221
140
255
1.2
400-800
WO-DN250
273
271-275
140
255
1.2
400-800
WO-DN300
325
323-327
140
255
1.0
400-800
WO-DN350
377
375-379
155
255
1.0
800-1200
WO-DN400
426
424-428
155
255
0.8
800-1200
WO-DN450
480
475-482
155
255
0.8
800-1200
WO-DN500
530
526-533
155
255
0.8
1200-1500
