French Type DSP Fire Hose Coupling Adapter With Male And Female Thread
We are the french type DSP fire hose coupling factory in china , the material can be aluminum ,brass .
the IMPA CODE is 330873 330874 . The DSP hose coupling is widely used in the frence .
The female and male parts are the same ,there are no difference . when you want to use ,you just connect and turn .
The DSP couping looks same with Guillemin Hose Coupling ,but there are have the small differences . the locker is differnet .
Size :1.5'' 2.5'' 4.0''
Material :ALU by gravity casting , Brass by forging ,
Seal: NBR, EPDM, FPM, PTFE
Thread: BSP NPT
Surface Treatment: Polishing or Sand-Blast
Female Thread
|
NAME |
SIZE |
ALU WEIGHT WITH LOCKING RING |
ALU WEIGHT WITHOUT LOCKING RING |
|
DN40 |
1.5'' |
0.24 |
0.09 |
|
DN40 |
2.0'' |
0.29 |
0.18 |
|
DN65 |
2.0'' |
0.49 |
0.30 |
|
DN65 |
2.5'' |
0.44 |
0.17 |
|
DN100 |
4.0'' |
1.15 |
0.54 |
Male Thread
|
NAME |
SIZE |
ALU WEIGHT WITH LOCKING RING |
ALU WEIGHT WITHOUT LOCKING RING |
|
DN40 |
1.5'' |
0.17 |
0.11 |
|
DN40 |
2.0'' |
0.21 |
0.19 |
|
DN65 |
2.0'' |
0.46 |
0.36 |
|
DN65 |
2.5'' |
0.36 |
0.25 |
|
DN100 |
4.0'' |
0.90 |
0.55 |
