Description
Oil Fuel Tanker Truck Aluminum 4 Inch API Adaptor Coupler / Gravity Drop Coupler
1. Gravity Drop Couple
The Gravity Drop Coupler improves the efficiency when doing the work of unloading. The oblique angle design is
convenient for gravity discharging to make the unloading much cleaner and faster.Effectively protect the hose not
be bended when unloading. Female-Coupler interface complies with the API RP1004 requirements, can be connected
with the standard API Coupler.
2. Feature
1. Aluminum alloy die-cast structure, anodized treatment.
2. Cam locking operation, installed by press.
3. 22.5 angle downward reduce oil retention.
4. Exclusively designed handle towards locking makes easier connection and more reliable sealing.
5. Cam and free-floating eliminates friction and bending, easier to connect without grease.
6. Easy to check the flow through the lamellar sight glass.
7. Used for many sections tankers, separate loading and unloading for different fuel.
8. Meets API1004 standard.
Product Name
High Quality API Adaptor
Material
body
aluminium
handle
Brass
Operating Method
Mechanical
Seal
NBR
Technical:
Casting
Specification
4x2.5 inches, 4x3 inches, 4x4 inches
Pressure:
0.6Mpa
Tempreture:
-20~+70℃
Medium:
Gasoline, Kerosene, Diesel
