Storz Adapter Female Thread

Product Item：WO-SAF-01

Material : Alumiunium A356-T6 (Heat Treated) Brass Stainless316

Sealing Material: NBR ,EPDM, FPM, PTFE

Size: 1''-12''

Casting Method: Forge Die-casting

Description

Storz Adapter Female Thread

We are the few factories ,who can make the SS316 storz coupling with the female thread in china .

We have the most size in stock ,our couping are covering the standard and the unatandards size .

We have the large size such as 6'' 8'' 10'' 12'' .

The thread can be BSP , NPT , NH .

The material can be ALU-DIE CAST ,ALU-FORGE, BRASS ,BRONZE,GUNMETAL,SS316 .

SIZE	IMPA CODE	DIN	STORZ
1.0''		DIN14301	Storz 25D
1.25''			Storz 32
1.5''(40A)	330871JM		Storz 38
2.0''(50A)	330875	DIN14321	Storz 52C
2.5''(65A)	330872JM		Storz 65
3.0''(75A)	330876	DIN14322	Storz 75B
4.0''		DIN14323	Storz 110A

NAME	KA/MM	D/MM	L/MM	ALU WEIGHT	BRASS WEIGHT	SS316 WEIGHT
SZF25/13	31	G1/2''	30	0.08	0.23	0.21
SZF25/20	31	G3/4''	30	0.08	0.23	0.21
SZF25	31	G1''	30	0.08	0.23	0.21
SZF32/25	44	G1''	31	0.08	0.25	0.23
SZF32	44	G1 1/4''	31	0.14	0.39	0.41
SZF38/25	51	G1''	33	0.15	0.47	0.44
SZF38/32	51	G1 1/4''	33	0.17	0.54	0.49
SZF38	51	G1 1/2''	33	0.15	0.47	0.47
SZF38/50	51	G2''	37.5	0.18	0.57	0.52
SZF45/50	59	G2''	35	0.24	0.76	0.70
SZF50/25	66	G1''	35.5	0.28	0.81	0.81
SZF50/32	66	G1 1/4''	35.5	0.30	0.74	0.70
SZF50/38	66	G1 1/2''	35.5	0.28	0.66	0.66
SZF50	66	G2''	40	0.28	0.80	0.77
SZF50/65	66	G2 1/2''	40	0.28	0.88	0.81
SZF65/25	81	G1''	36	0.53	1.67	1.54
SZF65/32	81	G1 1/2''	36	0.45	1.42	1.31
SZF65/50	81	G2''	40.5	0.38	1.51	1.40
SZF65	81	G2 1/2''	40.5	0.38	1.51	1.40
SZF65/75	81	G3''	39	0.41	1.20	1.10
SZF75/50	89	G2''	41	0.43	1.22	1.09
SZF75/65	89	G2 1/2''	42	0.42	1.24	1.06
SZF75	89	G3''	41.5	0.42	1.50	1.26
SZF100	115	G4''	48	0.85	2.65	2.46
SZF110	133	G4''	48	1.09	3.77	3.25
SZF110/115	133	G4 1/2''	48	1.09	3.77	3.25
