Description
Aluminum Brass Stainless Steel 316 French Type Hose Coupling
guillemin couplings are intended for application in industrial installations transferring, loading and unloading liquid
and dry loose substances. The couplings were first designed in France and are compliant with EN 14420-8 / NF E 29572.
Simple and easy connection is the key to their popularity. Two identical halves with two lugs are closed just by putting
them together with the seals facing each other and by turning the locking rings so that the lugs are securely engaged.
To tighten the connection,turn the locking rings with a hook wrench for guillemin couplings by 1/4 a turn.
Guillemin Couplings are used for delivery and suction-delivery applications for water, fluids, hydrocarbons, (including
bituminous substances), chemicals (stainless steel version) and dry loose materials (powders, granules). Not suitable for
steam and other gases.Used in industrial installations, irrigation, loading and unloading systems, as the equipment of road
and rail tankers.
Size :DN15-DN150
Material :ALU by gravity casting , Brass by forging ,Stainless Steel by investment casting ,Polypropylene.
Seal: NBR, EPDM, FPM, PTFE
Thread: BSP NPT
Surface Treatment: Polishing or Sand-Blast
| NAME | SIZE | ALU WEIGHT | BRASS WEIGHT | SS316 WEIGHT |
| DN15-20 | 1/2'' |
|
|
0.076 |
| DN20-20 | 3/4'' |
|
|
0.124 |
| DN20-25 | 3/4'' | 0.078 |
|
|
| DN25-25 | 1'' | 0.059 |
|
0.175 |
| DN25-30 | 1'' | 0.120 |
|
|
| DN32-32 | 1-1/4'' | 0.121 |
|
0.17 |
| DN32-35 | 1-1/4'' |
|
|
0.383 |
| DN40-40 | 1-1/2'' | 0.170 |
|
0.346 |
| DN40-45 | 1-1/2'' | 0.251 |
|
0.930 |
| DN50-51 | 2'' | 0.330 |
|
0.870 |
| DN50-55 | 2'' | 0.380 |
|
1.050 |
| DN65-65 | 2-1/2'' | 0.411 |
|
1.110 |
| DN65-70 | 2-1/2'' | 0.600 |
|
2.270 |
| DN80-76 | 3'' | 0.770 |
|
2.280 |
| DN80-80 | 3'' | 0.790 |
|
2.289 |
| DN80-90 | 3'' | 0.850 |
|
2.310 |
| DN80-90 | 4'' | 1.330 |
|
2.333 |
| DN100-100 | 4'' | 1.518 |
|
|
| DN100-105 | 4'' | 1.520 |
|
|
| DN100-110 | 4'' | 1.525 |
|
2.340 |
| DN125-125 | 5'' |
|
|
|
| DN150-152 | 6'' |
|
|
5.300 |
